Tattu Dual-channel smart charger 60A/3200W for 6S-14S Ultra High Voltage Tattu Smart battery

The TA3200UHV is a member of the Tattu premium intelligent Smart charger line, able to charge safely and conveniently Tattu/GensAce 6-14S Smart Batteries and 4.4V / 4.45V Ultra High Voltage Soft Pack Batteries.

The TA3200UHV charger features 2 powerful charge channels with its maximum power reaching up to 3200W/60A and recognizes batteries equipped with the DroneCAN protocol standard, therefore keeping primarily safety as well as smooth and simple operation as priority.

Additionally, the TA3200UHV supports communication with Smart batteries for intelligent charging and is capable of charging ultra-high-voltage (UHV) soft pack batteries. It also supports charging for 4.4V and 4.45V cells. For 4.4V batteries, users should select the LiXHV mode, while for 4.45V batteries, the LiUHV mode is recommended. In soft pack battery charging mode, the charger offers three charging current options: 6A, 16A, and 32A with a 220V input, or 10A, 16A, and 22A with a 110V input.

In all modes, while charging you can safely rely on the ability to follow real time parameters on the large LCD display like:

· Battery state of charge percentage

· Current status of charge

· Battery voltage

· Cell Voltage differences

· Charging current

To increase the charger and battery its operational efficiency and cycle life reliability we have added several smart features:

· Powerful internal fan to keep operational temperatures under total control

· Smart charge software algorithms to improve battery efficiency and therefore cycle life

· Sturdyprotective durable hard case to protect it from shocks and intensive usage

· High duty gold plated internal charge connectors with dust protection covers

· Convenient Carry-on handle for comfort placement and transport

· USB port allows for the latest software updates

· Multi-lingual instruction manual with detailed information and excellent after-sales service

SPECIFICATIONS

· AC Input: 100-240V

· Max Output Power: AC100-110V 1200W, 220-240 3200W

· Charge Current: Up to 60A

· Size: 276x154x216mm

· Weight: Approximately 6000g

· Battery Type: 6-14S Smart battery, 6-14S LiXHV- 4.4V Softpack and LiUHV- 4.45V Softpack

· Mode: Charging, Storage
